Crest fixing of profiled composite panels to medium steel sections
BIMETAL 304 Hex Washer Head, Double Threaded Self-Drilling Fastener with OD19mm Stainless Steel 304 Bonded EPDM Washer.
| Size | Drilling Capacity | Drive System |
|---|---|---|
| B2 HWH #12-14x55mm TT | 6mm | 8mm HEX |
| B2 HWH #12-14x60mm TT | 6mm | 8mm HEX |
| B2 HWH #12-14x65mm TT | 6mm | 8mm HEX |
| B2 HWH #12-14x70mm TT | 6mm | 8mm HEX |
| B2 HWH #12-14x75mm TT | 6mm | 8mm HEX |
| B2 HWH #12-14x80mm TT | 6mm | 8mm HEX |
| B2 HWH #12-14x90mm TT | 6mm | 8mm HEX |
| B2 HWH #12-14x100mm TT | 6mm | 8mm HEX |
| B2 HWH #12-14x125mm TT | 6mm | 8mm HEX |
| B2 HWH #12-14x150mm TT | 6mm | 8mm HEX |
| B2 HWH #12-14x200mm TT | 6mm | 8mm HEX |
Crest fixing of profiled composite panels to hot-rolled steel sections
BIMETAL 304 Hex Washer Head, Double Threaded, D5 Drill Point, Self-Drilling Fastener with OD19mm Stainless Steel 304 Bonded EPDM Washer.
| Sizes | Drilling Capacity | Drive System |
|---|---|---|
| B2 HWH #12-24x55mm TTD5 | 12.5mm | 8mm HEX |
| B2 HWH #12-24x65mm TTD5 | 12.5mm | 8mm HEX |
| B2 HWH #12-24x75mm TTD5 | 12.5mm | 8mm HEX |
| B2 HWH #12-24x100mm TTD5 | 12.5mm | 8mm HEX |
| B2 HWH #12-24x125mm TTD5 | 12.5mm | 8mm HEX |
| B2 HWH #12-24x150mm TTD5 | 12.5mm | 8mm HEX |
| B2 HWH #12-24x175mm TTD5 | 12.5mm | 8mm HEX |
More range are available, for further information contact us at info@fds-org.com
