Crest fixing of profiled roofing sheet to medium steel sections
Hex Washer Flange, Double Threaded Self-Drilling Fastener with Grey EPDM Washer.
| Size | Drilling Capacity | Drive System |
|---|---|---|
| EH HWF #12-14x45mm TT | 6mm | 8mm HEX |
| EH HWF #12-14x50mm TT | 6mm | 8mm HEX |
| EH HWF #12-14x55mm TT | 6mm | 8mm HEX |
| EH HWF #12-14x60mm TT | 6mm | 8mm HEX |
| EH HWF #12-14x65mm TT | 6mm | 8mm HEX |
| EH HWF #12-14x70mm TT | 6mm | 8mm HEX |
| EH HWF #12-14x75mm TT | 6mm | 8mm HEX |
| EH HWF #12-14x90mm TT | 6mm | 8mm HEX |
| EH HWF #12-14x100mm TT | 6mm | 8mm HEX |
| EH HWF #12-14x110mm TT | 6mm | 8mm HEX |
| EH HWF #12-14x120mm TT | 6mm | 8mm HEX |
| EH HWF #12-14x130mm TT | 6mm | 8mm HEX |
Crest fixing of profiled sheeting to hot-rolled steel
Hex Washer Head, Double Threaded, D5 Drill Point, Self-Drilling Fastener with OD16mm Aluminium Bonded EPDM Washer.
| Size | Drilling Capacity | Drive System |
|---|---|---|
| EH HWH #12-24x55mm TTD5 | 12.5mm | 8mm HEX |
| EH HWH #12-24x65mm TTD5 | 12.5mm | 8mm HEX |
| EH HWH #12-24x75mm TTD5 | 12.5mm | 8mm HEX |
| EH HWH #12-24x85mm TTD5 | 12.5mm | 8mm HEX |
| EH HWH #12-24x110mm TTD5 | 12.5mm | 8mm HEX |
| EH HWH #12-24x130mm TTD5 | 12.5mm | 8mm HEX |
| EH HWH #12-24x150mm TTD5 | 12.5mm | 8mm HEX |
| EH HWH #12-24x210mm TTD5 | 12.5mm | 8mm HEX |
More range are available, for further information contact us at info@fds-org.com
